Temperature Control Units ■
Unit
classification
Product
name
Specifications
No. of
unit
numbers
allocated
Current
consumption
(A) Model Standards
No. of loops
Temperature
sensor inputs
Control outputs 5 V 24 V
CJ Special
I/O units
Temperature
Control Units
4 loops
Thermocouple
input (R, S, K, J,
T, B, L)
Open collector NPN
outputs (pulses)
2
0.25 — CJ1W-TC001
UC1, N, L,
CE
4 loops
Open collector PNP
outputs (pulses)
0.25 — CJ1W-TC002
2 loops, heater
burnout detection
function
Open collector NPN
outputs (pulses)
0.25 — CJ1W-TC003
2 loops, heater
burnout detection
function
Open collector PNP
outputs (pulses)
0.25 — CJ1W-TC004
4 loops
Platinum
resistance
thermometer input
(JPt100, Pt100)
Open collector NPN
outputs (pulses)
0.25 — CJ1W-TC101
4 loops
Open collector PNP
outputs (pulses)
0.25 — CJ1W-TC102
2 loops, heater
burnout detection
function
Open collector NPN
outputs (pulses)
0.25 — CJ1W-TC103
2 loops, heater
burnout detection
function
Open collector PNP
outputs (pulses)
0.25 — CJ1W-TC104
High-speed Counter Unit ■
Unit
classification
Product
name
Specifications No. of
unit
numbers
allocated
Current
consumption
(A)
Model Standards
Countable
channels
Encoder A and B inputs,
pulse input Z signals
Max.
counting
rate
5 V 24 V
CJ Special
I/O units
High-speed
Counter Unit
2
Open collector
Input voltage: 5 VDC, 12 V, or 24 V
(5 V and 12 V are each for one
axis only.)
50 kcps
4 0.28 — CJ1W-CT021
UC1, N, L,
CE
RS-422 line driver
500 kcps
Position Control Units ■
Unit
classification
Product
name
Specifications
No. of
unit
numbers
allocated
Current
consumption
(A) Model Standards
No. of
axea
Control output interface 5 V 24 V
CJ Special
I/O units
Position
Control
Units 1 axis Pulse train, open collector output
1
0.25 — CJ1W-NC113
UC1, CE
2 axes Pulse train, open collector output 0.25 — CJ1W-NC213
4 axes Pulse train, open collector output (See note.) 2 0.36 — CJ1W-NC413
1 axis Pulse train, line driver output
1
0.25 — CJ1W-NC133
2 axes Pulse train, line driver output 0.25 — CJ1W-NC233
4 axes Pulse train, line driver output (See note.) 2 0.36 — CJ1W-NC433
Space Unit Use a CJ1W-SP001 Space Unit if the operating temperature is 0 to 55 °C. CJ1W-SP001 UC1, CE
Note: The ambient operating temperature for 4-Axis Position Control Units is 0 to 50°C; the allowable voltage fluctuation on the external 24-VDC power supply is 22.8 to 25.2 VDC (24 V ±5%).
