Ordering Information
Expansion Racks
Select the I/O Control Unit, I/O Interface Unit, Expansion Connecting Cable, and CJ-series Power Supply Unit.
CJ-series I/O Control Unit (Mounted on CPU Rack when Connecting Expansion Racks) ■
Product name Specifications
Current
consumption (A) Model Standards
5 V 24 V
CJ-series I/O
Control Unit
Mount one I/O Control Unit on the CJ-series CPU Rack when connecting one
or more CJ-series Expansion Racks.
Connecting Cable: CS1W-CN
3 Expansion Connecting Cable
Connected Unit: CJ1W-II101 I/O Interface Unit
Mount to the right of the CPU Unit.
0.02 — CJ1W-IC101
UC1, N, L,
CE
Note: Mounting the I/O Control Unit in any other location may cause faulty operation.
CJ-series I/O Interface Unit (Mounted on Expansion Rack) ■
Product name Specifications
Current
consumption (A) Model Standards
5 V 24 V
CJ-series I/O
Interface Unit
One I/O Interface Unit is required on each Expansion Rack.
Connecting Cable: CS1W-CN
3 Expansion Connecting Cable
Mount to the right of the CPU Unit.
0.13 — CJ1W-II101
UC1, N, L,
CE
Note: Mounting the I/O Interface Unit in any other location may cause faulty operation.
I/O Connecting Cables ■
Product name Specifications Model Standards
I/O Connecting
Cable • Connects an I/O Control Unit on CJ-series CPU Rack to an I/O Interface Unit on a
CJ-series Expansion Rack.
or
• Connects an I/O Interface Unit on CJ-series Expansion Rack to an I/O Interface Unit on
another CJ-series Expansion Rack.
Cable length: 0.3 m CS1W-CN313
N, L, CE
Cable length: 0.7 m CS1W-CN713
Cable length: 2 m CS1W-CN223
Cable length: 3 m CS1W-CN323
Cable length: 5 m CS1W-CN523
Cable length: 10 m CS1W-CN133
Cable length: 12 m CS1W-CN133-B2
