LCD Display Information
AUTHOR A
25M01S
2H33M25S
AUTHOR A
E F
25M01S
2H33M25S
1 Recording level meter
Displays the sound input level
graphically and the remaining
time available for recording in
countdown mode.
2 Remaining memory bars
Displays the remaining time
available for recording in bar
mode and countdown mode.
While in record mode
1 VCVA recording level
meter
Displays the sound input level
graphically and the remaining
time available for recording in
countdown mode.
(“STANDBY” appears if the VCVA
actuation level isn’t reached.)
2 Remaining memory bars
Displays the remaining time
available for recording in bar
mode and countdown mode.
AUTHOR A
25M01S
2H33M25S
AUTHOR A
E F
25M01S
2H33M25S
While recording in VCVA mode
AUTHOR ID
10M25S
14M00S
AUTHOR ID
10M25S
14M00S
E F
1 Recording level meter
Displays the sound input level
graphically, the current time
and the length of the file.
2 Remaining memory bars
Displays the remaining time
available for recording in bar
mode, and the current time
and length of the file.
While in Overwrite Record Mode
1 Recording level meter
Displays flashing “INSERT
REC”, the sound input level
graphically, and the current
recording time.
2 Remaining memory bars
Displays flashing “INSERT
REC”, the remaining time
available for recording in bar
mode, and the current
recording time.
AUTHOR ID
1H25M01S
INSERT REC
AUTHOR A
1H25M01S
I NSERT REC
E F
While in Insert Record Mode
