Parallel Input Cable (Centronics 36 pin)
Pin # Description
1 STROBE
2~9 Data bits 0-7
10
ACK
11 Busy
12 PE (Paper End)
13 Select, always high
16 Signal Ground
17 Chassis Ground
18 +5V DC
19~30 Ground
32 Fault
Serial Port Parameters
OKIPOS X400 printers are configured as Data Terminal Equipment
(DTE) equipment, and use Request-To-Send/Clear-To-Send (RTS/CTS)
handshaking or X-On/X-Off flow control (control characters are DC2
and DC4). The serial port supports the following parameters:
Speed 9600,19200 or 38400 bps
Parity Odd, Even or None
Data Bits 7 or 8 bits
Stop Bit(s) 1 or 2
Default Parameters 9600 bps, No parity, 8 data bits, 1
stop bit
22
