Printer Specifications
OKIPOS X400
Print Method Thermal Transfer or Direct Thermal
Max Ribbon Length 328 ft. (100m)
Max Ribbon Roll OD 1.5 in. (38mm)
Ribbon Core ID 0.5 in.(12.8mm)
Ribbon Core OD 0.72 in. (18.4mm)
Weight (including
power module) 8.1 lbs. (3.67kg)
Print Head Density 203 dpi (8 dot/mm)
Print Speed 1 ips (25.4mm/s), 2 ips (50.8mm/s), 3 ips
(76.2mm/s), 4 ips (101.6mm)
Media Continuous paper, Paper Labels, Vinyl Labels,
Tag
Media Width 4.3 in. (108mm)
Max Roll Diameter 5 in. (127mm)
Label Roll Core ID 1 in. (25.4mm)
Max Print Width 4.1 in. (104mm)
Max Print Length 50 in. (1270mm)
Min Label Length .39 in. (10mm)
Min Inter-Label Gap 0.08 in. (2mm)
Max Inter-Label Gap 1 in. (25.4mm)
Media Sensing
(Left side, adjust-
able) See-through sensor for die-cut gap or
notched media;
Reflective sensor for Eye-mark;
Continuous Material
Interface Ports 9-pin RS232 Serial & 36-pin Centronics
Baud rate 9600, 19200 & 38400 bps
Flow Control X-On/X-Off and RTS/CTS protocols
19
