5
Mounting the Optional PTSA-01 Short Arm
The separately available PTSA-01 short arm can be mounted on the end of the bracket grip.
Loosen the short arm clamping screw of the separately available optional short arm.
Attach the short arm while taking care that it does not interfere with the rotation stopper boss.
* For removal, reverse the mounting procedure.
Tighten the short arm clamping screw.
Storage Precautions
● After using this product in sea water, immerse it in pure water to remove any salt.
● Be sure to detach this product from the PT-E series underwater case before storage.
● Never use alcohol, gasoline, lacquer thinner, benzine or similar organic solvents or chemical
detergents to clean this product. Such chemicals can damage the product and cause it to deterio-
rate.
● Do not store this product when it has moisture, sand or dust on it.
Specifications
Dimensions: Width 308 mm x Height 155 mm x Depth 40 mm / Thickness 6 mm (max.)
Weight: 350 grams
Shinjuku Monolith, 3-1 Nishi Shinjuku 2-chome, Shinjuku-ku, Tokyo, Japan
Two Corporate Center Drive, Po Box 9058, Melville, NY 11747-9058, U.S.A.
Tel. 631-844-5000
Technical Support (USA)
24/7 online automated help: http://www.olympusamerica.com/support
Phone customer support: Tel. 1-888-553-4448 (Toll-free)
Our phone customer support is available from 8 am to 10 pm
(Monday to Friday) ET
E-Mail: [email protected]
Olympus software updates can be obtained at:
http://www.olympus.com/digital/
European Technical Customer Support:
Please visit our homepage http://www.olympus-europa.com
or call our TOLL FREE NUMBER* : 00800 - 67 10 83 00
Premises : Wendenstrasse 14-18, 20097 Hamburg, Germany
Tel: +49 40-23 77 3-0 Fax: +49 40-23 07 61
Goods delivery : Bredowstrasse 20, 22113 Hamburg, Germany
Letters
: Postfach 10 49 08, 20034 Hamburg, Germany
For all not listed European Countries and in case that you
can’t get connected to the above mentioned number please
make use of the following
CHARGED NUMBERS:
+49 180 5 - 67 10 83 or +49 40 - 237 73 899
Our Technical Customer Support is available from 9am to 6pm MET
(Monday to Friday)
for Austria, Belgium, Denmark, Finland, France, Germany,
Italy, Luxemburg, Netherlands, Norway, Portugal, Spain,
Sweden, Switzerland, United Kingdom
*Please note that some (mobile) phone services/ provider do
not permit access or request an additional prefix to +800
numbers.
© 2005 OLYMPUS IMAGING CORP.
Rotation stopper boss
