Oki POS 425S User Manual
Page 84

84
OKIPOS 425S
|
5.7.5.3.7 Binding Holes
Do not use a paper with punched holes. It may invalidate your warranty.
If you choose to use punched paper, be sure to test it thoroughly. Follow these guidelines:
1
Do not print within 5 mm of the hole center.
2
Make sure that paper dust is not left on the paper.
3
If a hole passes over the paper sensor, a false paper end signal may result.
4
Make sure that the edges of holes are even with the paper surface. If they stick up, the printhead may not move
smoothly.
5
The positions of holes should be as illustrated in the figure below.
OP425_26.eps
1
10 or more
2
o 10 (shaded area) Do not print.
3
Binding hole
4
Unit: mm
1
1
1
1
2
3
4
