Oki POS 425S User Manual
Page 70

70
OKIPOS 425S
|
2
Counterfoil and Stub
OP425_11.eps
1
Printing area
2
Stub
3
Inserting direction
A25023.doc
Symbol
Designation
Standard Value
W
Paper width
70mm (2.76 inch) or more
L
Paper length
40mm (1.57 inch) or more
A
Print starting position
18mm (0.7 inch) or less
B
Left margin
2.54mm (0.1 inch) or more
C
Right margin
2.54mm (0.1 inch)
D
Printing area width
Max 160.02mm (6.3 inch)
Note 1 To feed paper, insert a paper from the top side of the device and keep holding it until printing ends.
Note 2 Use a flat sheet free curls, bends (especially those on its edges), cambers, wrinkles, etc. If a sheet is not flat, it may
be contaminated with ink due to ink ribbon contact.
Note 3 Before printing on a stub, fold the other sheets backward to make the stub available for print as shown in the fig.
below.
OP425_12.eps
1
Fold backward
2
Stub
2
3
1
1
2
