15
USING THE UNIT SAFELY .
For the Snare (PDX-8) to function correctly, trigger parameters in the sound module
TD-3 must be adjusted.
For more detailed informations, refer to the TD-3 Owner’s Manual.
.
When adding a new pad, use trigger input CRASH2.
Adding a Cymbal
Adding the CY-8 or the CY-5 for a 2nd Crash or a Splash Cymbal. For mounting, use the Cymbal Mount
MDY-10U.
Adding a Tom
Adding the PD-8 for a 2nd floor tom. For mounting, use the Pad Mount MDH-10U.
Kick Trigger Pad: KD-8, KD-7
V-Kick Trigger Pad: KD-85, KD-120
Dual Trigger Pad: PD-8
V-Pad: PDX-8, PD-85, PD-105, PD-125
Cymbal Pad: CY-8, CY-5
V-Cymbal: CY-12R/C, CY-14C, CY-15R
Pad Mount: MDH-10U
Cymbal Mount: MDY-10U
Trigger Settings For TD-3
Adding the Optional Pads to the TD-3KW
Examples
Options
