Specifications
Runco CX-52HD/CX-57HD Owner’s Operating Manual 59
PRE
L
IMINAR
Y
7.2
Crystal Series LCD
Dimensions Figure 7-1 and Figure 7-2 show the Crystal Series LCD dimensions (all dimensions are in
inches).
Figure 7-1. CX-52HD Dimensions
49.84
23.62
W
all Mount Screw
6 x M8 T
ap
45.35
4.51 9.84
7.87 7.87 5.55
25.51
3.72 30.00
33.72
