Page 48: Pre l iminar y
32
PlasmaWall XP Series Installation/Operation Manual
PRE
L
IMINAR
Y
Connecting AC Power
Plug the female end of the power cord into the AC receptacle on the rear of the
PlasmaWall. Connect the other end to your AC power source. (The XP-103DHD requires
200-240 VAC.)
Figure 3-14. AC Power Connection
Similarly connect the DHD Controller to a nearby AC outlet.
➤
XP-50DHD / XP-OPAL50DHD
XP-65DHD / XP-OPAL65DHD
XP-103DHD (NOTE: The XP-103DHD requires 200 - 240 VAC)
