1. Put the Plate-Unwinder R on the inner side of the frame as shown in the following figure
and fasten it with four M6 hexagonal bolts.
2. Put the Plate-Unwinder L on the inner side of the frame as shown in the following figure
and fasten it four M6 hexagonal bolts.
SETTING UP FILM
주
름
방
지
부
열
판
주
름
방
지
부
열
판
L
C
D
표
시
창
버
튼
부
M6 hexagonal
bolt
Plate-Unwinder R
