Page 7
take -up motor.
7. Assemble the Right cover letting the wires go through the slot which is located at the rear side
of the Right cover.
8. Put the Power switch bracket on the Plate-Rewinder L and fasten it with two M4 screws.
How to install the unwinder
Female Connector from
take-up motor
Male Connector from
rewinder motor
Power switch bracket
Plate-Rewinder L
- 7 -
