Royal Sovereign 1050 - Manual (Page 24)

Extreme Heat Will Cause Injury
3.Place the machines on the plated place so that
4.Make certain that the machine is connecterd to an adequate power souce.
5.Do not use any other purposes other than
Lamination.
1.Do not allow the machine to run with only one roll of film installed. The
melted resin will adhere to one roller and ruin future laminations.
2.The width of film should be bigger than the material, and
Width of upper side and lower side of film should be same in order not to allow
melted resin to adhere to the rollers.
3.Be sure to adjust the film tension while in operation.
If the tension is too tight, it could cause the film to stretch.
4.After work, you should clean the resin from
the rollers before beginning the next operation.
5.Please check the lubricant after long operation
or you do not use for a long time.
6.Check the chain linking each gear is not loosened.
The limit tension allowed is 3mm.
*Rollers do not operate 1. Power cord may not be plugged 1. Check the power cord
after press RUN button in. 2. Check the switch is on
2. Power switch is at OFF mode. 3. Check the emergency switch
3. Emergency switch may be at is off
ON mode. 4. Release STND-BY switch by
MAINTENANCE
It's not out of order
Cause Check point Symptom
- 24 -
