28
2.2.7 Note on Setting the UBC_MODE Command
In the [Configuration] dialog box, if [User] is set while the [UBC mode] list box has been set, the
STEP-type commands that use Break Condition 2 for implementation cannot be used.
2.2.8 Performance Measurement Function
The SH7710 E10A emulator supports the performance measurement function.
1. Setting the performance measurement conditions
To set the performance measurement conditions, use the [Performance Analysis] dialog box
and the PERFORMANCE_SET command. When any line on the [Performance Analysis]
window is clicked with the right mouse button, the popup menu is displayed and the
[Performance Analysis] dialog box is displayed by selecting [Setting].
Note: For the command line syntax, refer to the online help.
(a) Specifying the measurement start/end conditions
The measurement start/end conditions are specified in the [Mode] drop-down list box in the
[Performance Analysis] dialog box. Three conditions can be set as shown in table 2.9.
Table 2.9 Conditions Specified in [Mode]
Item Description
Normal break Measurement is started by executing a program and ended when a
break condition is satisfied.
Break Condition 1 -> 2 Measurement is started from the satisfaction of the condition set in
Break Condition 1 and ended with the satisfaction of the condition set in
Break Condition 2.
Break Condition 2 -> 1 Measurement is started from the satisfaction of the condition set in
Break Condition 2 and ended with the satisfaction of the condition set in
Break Condition 1.
