19

Table 2.5 lists the combinations of conditions that can be set under Break Condition 1, 2, 3.

Table 2.5 Dialog Boxes for Setting Break Conditions

Type





Dialog Box


Address
Bus
Condition
(Address)


Data
Bus
Condition
(Data)



ASID
Condition
(ASID)

Bus
State
Condition
(Bus
Status)



Count
Condition
(Count)



Internal
I/O
Break



LDTLB
Instruction
Break

[Break Condition 1]
dialog box

O

O

O

O O

X X

[Break Condition 2]
dialog box

O

X

O

O

X X X

[Break Condition 3]
dialog box

X X X X

X

O

O

Notes: 1. O: Can be set in the dialog box.

X: Cannot be set in the dialog box.

2. For Break Condition 2, X-bus and Y-bus conditions cannot be specified.

2.2.3 Trace

Functions

The SH7710 E10A emulator supports the trace functions listed in table 2.6.

Table 2.6 Trace Functions

Function

Internal Trace

AUD Trace

Branch trace

Supported (eight branches)

Supported

Range memory access trace

Not supported

Supported

Software

trace

Not

supported Supported

Table 2.7 shows the type numbers that the AUD function can be used.

Table 2.7 Type Number and AUD Function

Type Number

AUD Function

HS7710KCM01H, HS7710KCI01H

Not supported

HS7710KCM02H, HS7710KCI02H

Supported
