Make and follow a route – Raymarine 530 User Manual
Page 44
2-20
SL520/530/631 PLUS Chartplotter Displays
Ma
ke
an
d F
ollo
w
a
Ro
ut
e
Make and Follow a Route
#
GOTO
SCREEN
ROUTE
FIND SHIP
MAKE
ROUTE
EDIT
ROUTE
CLEAR
ROUTE
MORE¬
2
2. Press the soft key
1
3
4
Press the soft key
D4268-1
Press the soft key
1. Position Cursor - in this example
over an existing waypoint
Position Cursor for next waypoint,
then press soft key.
Repeat to plot all waypoints in
sequence.
