Page 24

1-12
SL520/530/631 PLUS Chartplotter Displays
Dat
abase Li
sts
Data
ba
se
List
s
Database Lists
The waypoints, routes and tracks that you create on the chartplotter are stored
in database lists. You can view these lists and select items for editing.
Figure 1-4:
Typical Database List
As with pop-up menus, when a database list is on-screen, a set of associated
soft keys is also displayed; you use the trackpad to select an item from the list,
then use the appropriate soft key to edit the item. For example, you can erase a
waypoint or a route.
GOTO
WAYPOINT
EDIT
WAYPOINT
MAKE NEW
WAYPOINT
WAYPOINT
TRANSFER
D4262-2
WAYPOINT LIST
SYMBOL NAME
WAYPOINT 001
WAYPOINT 002
WAYPOINT 003
WAYPOINT 004
WAYPOINT 005
50°21^966N
001°20^368W
POSITION
BRG _186°
RNG _21.0nm
TEMP
---°
C
DEPTH
---
m
DATE --/--/--
TIME --:--:--
