C-2
SL520/530/631 PLUS Chartplotter Displays
Se
aT
alk
a
nd
N
M
EA
Data
R
eceiv
ed
and
Tran
smitted
The display unit transmits the following data, if available, on SeaTalk:
4
Bridged from NMEA if selected in the System Set Up menu.
Data Output
SeaTalk
NMEA Out
Position (LAT/LON)
✔
GGA, GLL, RMC, RMA
Position (Loran C TD’s)
✔
RMA
Speed Over Ground and
Course Over Ground
✔
RMC, VTG
,
,
RMA
Waypoint Data
✔
RMB, APB, BWC, BWR
Depth
✔
Apparent Wind Angle and Speed
✔
—
Boat Speed Through Water
✔
—
Total Log and Trip Log
✔
Water Temperature
✔
Heading
✔
VHW
Magnetic Variation
✔
RMA, RMC
Time
✔
ZDA
Date
✔
ZDA
MOB data
✔
—
Cursor Range & Bearing
✔
RSD
2
Heading mode
—
RSD
2
Waypoint/Route Transfer
—
WPL, RTE
Global Alarm
Waypoint Arrival Alarm
SeaTalk
—
APB, RMB
