Customizing the Screen Presentation Options
The SCREEN soft key lets you switch the following screen presentation options
on or off:
Switching the Cursor Data Box On and Off
The cursor data box provides the cursor’s position in latitude/longitude and/or
bearing/range. If you wish to see a full image, you can switch the data box off.
➤ To control the cursor data box:
1. Press the SCREEN soft key.
2. Press the CRSR BOX soft key to toggle the setting from OFF to ON or from ON
to OFF.
3. To return to the default soft key display, press ENTER.
➤ You can use the context sensitive cursor to select and move the cursor data box
(the label BOX is displayed). See Moving and deleting items with the context-
sensitive cursor on page 1-9
Switching Chart Grid On and Off
The Chartplotter display includes grid lines of latitude and longitude which
you can use to help determine position on the chart. The grid lines can be
switched on if required.
➤ To turn the chart grid on or off:
1. Press the SCREEN default soft key.
2. Press the CHRT GRID soft key to toggle the setting from OFF to ON or from
ON to OFF.
To return to the default soft key display, press ENTER.
Data Boxes
A group of up to six data boxes can be displayed, if the information is available
on your system. You select which data is displayed in the boxes during
system set up as described in Chapter 5:Setting Up the System Defaults.
The default data box positions are along the bottom of the display. Each box
can be moved to the required position on the screen using the context-sensitive
cursor.
