ST30 Bidata Operation and Installation Handbook
Package Contents
The following items are included in the ST30 Bidata package:
1. ST30 Bidata instrument
2. Fixing studs (2 off)
3. Thumb nuts (2 off)
4. Mounting template
5. 1m power cable
6. Depth transducer (through hull) with 10m cable and 1/8in spade
connectors
7. Speed transducer (through hull) with 10m cable and 1/8in spade
connectors (0 to 32 knots)
8. Instrument cover
9. Operation and installation handbook
10. High speed paddle wheel (2 to 45 knots)
11. Daisy-chain cable
DEPTH
SPEED
TM BIDATA
DEPTH SPEED RESET
ST30 INSTRUMENT
MOUNTING TEMPLATE
2-HOLES
DRILL 5mm
( .197" ) DIA
1-HOLE
DRILL 60.3mm
( 2,3/8" ) DIA
TM
TM
ST30
BIDATA
Operation and
Installation
D680
SeaTalkSeaTalk
SeaTalkSeaTalk
1
11
SeaTalkSeaTalk
6 7
5
2
3
8
4
9
10
