Chapter 5: Operation
21
Chapter 5: Operation
The ST30 Bidata is set in the factory to:
• display depth in feet
• display speed in knots
• operate with the depth alarms switched off
• operate in Master mode
These settings can be changed in calibration (section 6.1).
When the ST30 Bidata is switched on, depth information (upper display)
and speed information (lower display) is shown in the units set up in
calibration.
Knots
Metres
DEPTH
SPEED
D710
Note: The trend arrows (▲) decreasing (▼) increasing, shown in the above
display, indicate whether the trend is towards deep or shallow water.
5.1 Depth Key
Each press of Depth cycles the following menu:
• Shallow alarm
Knots
Metres
DEPTH
SPEED
D710
Shallow
