2 speed calibration, Units selection – speed, Bidata – Raymarine stand-alone master instrument User Manual
Page 34: Cycle speed until knots or mph is displayed, Press reset to change between knots and mph
Chapter 6: Calibration
31
6.2 Speed calibration
The ST30 Bidata can be set to display speed in knots or mph and trip and
total distance in nm or miles. The most important speed calibration feature
is Log Calibration; this calibrates the transducer paddlewheel to the
vessel's hull so that accurate speed/log related information is displayed.
Press and hold
and Depth for 2 seconds until CAL is displayed.
Units selection – speed
1.
Cycle Speed until knots or mph is displayed.
TM
D695
BIDATA
DEPTH
SPEED
RESET
Knots
DEPTH
SPEED
2.
Press Reset to change between knots and mph.
TM
D696
BIDATA
DEPTH
SPEED
RESET
Mph
DEPTH
SPEED
