28
MENU DESCRIPTION AND NAVIGATION
Manual
White
Red
Green
Blue
Manual Indicates you are in the Manual Gamut setting mode using a
calibrated colorimeter. Note that changes are not made till
you EXIT this menu
White X=0.XXX Press ENTER to change the White X value using the Left
and Right arrows to select the digit to change and the Up and
Down arrows to change, then ENTER to effect
White Y=0.YYY Press ENTER to change the White Y value using the Left
and Right arrows to select the digit to change and the Up and
Down arrows to change, then ENTER to effect
Red X=0.XXX Press ENTER to change the Red X value using the Left and
Right arrows to select the digit to change and the Up and
Down arrows to change, then ENTER to effect
Red Y=0.YYY Press ENTER to change the Red Y value using the Left and
Right arrows to select the digit to change and the Up and
Down arrows to change, then ENTER to effect
Green X=0.XXX Press ENTER to change the Green X value using the Left
and Right arrows to select the digit to change and the Up and
Down arrows to change, then ENTER to effect
Green Y=0.YYY Press ENTER to change the Green Y value using the Left
and Right arrows to select the digit to change and the Up and
Down arrows to change, then ENTER to effect
Blue X=0.XXX Press ENTER to change the Blue X value using the Left and
Right arrows to select the digit to change and the Up and
Down arrows to change, then ENTER to effect
Blue Y=0.YYY Press ENTER to change the Blue Y value using the Left and
Right arrows to select the digit to change and the Up and
Down arrows to change, then ENTER to effect
Procedure:
1. Set up PR or Milori color meter
2. Enter manual Gamut setting menu
3. Measure X and Y values of White
4. Enter measured values by scrolling to the digit to be changed, use the up and down keys to change it and then moving
to the next digit. Hit ENTER to save the numbers.
5. Repeat the above procedure with the red, green and blue values exit the Gamut setting menu all the way back to
NORMAL to establish the changes
COLOR SPACE COORDINATES FOR REFERENCE
GAMUT X Y GAMUT X Y
EBU red 0.64 0.33 NTSC red 0.67 0.33
EBU green 0.29 0.6 NTSC green 0.21 0.71
EBU blue 0.15 0.06 NTSC blue 0.14 0.08
SMPTE C red 0.635 0.340 Graphics red 0.628 0.346
SMPTE C green 0.305 0.595 Graphics green 0.268 0.588
SMPTE C blue 0.155 0.070 Graphics blue 0.15 0.07
