25
MENU DESCRIPTION AND NAVIGATION
Color Enable
Red
Green
Blue
Yellow
Cyan
Magenta
Color Enable Indicates you are in the Color Enable menu
Red Press ENTER to turn Red On
Green Press ENTER to turn Green On
Blue Press ENTER to turn Blue On
Yellow Press ENTER to turn Red Off
Cyan Press ENTER to turn Blue Off
Magenta Press ENTER to turn Green Off
Ext Test
Color Bar 75 IRE
Color Bar 100 IRE
External H Ramp
Ext Test Indicates you are In the External front end board Test mode
Color Bar 75 IRE Press ENTER to display the high brightness color bars
Color Bar 100 IRE Press ENTER to display the low brightness color bars
External H Ramp Press ENTER to display the External Horizontal Ramp test
From the Diagnose menu use the Up or Down arrow to select “Color Enable” and press the Enter button to call
up the Service options.
Use the Up or Down button to indication your selection and press the Enter button to make your selection.
Press the Menu button to exit.
From the Diagnose menu use the Up or Down arrow to select “Ext Test” and press the Enter button to call up the
Service options.
Use the Up or Down button to indication your selection and press the Enter button to make your selection.
Press the Menu button to exit.
