While there are many different ways to connect your source equipment to your DHD Controller, the examples below are the
most common.
ANALOG INPUTS:
• Composite Video Input
Composite video is the most common type of signal used, but is also the lowest in picture quality. Many sources have outputs
that are limited to composite video, such as some VCR’s and camcorders; others such as Laser Disc players actually produce
slightly better results when using composite video.
• S-Video Input
S-video is the second-best type of signal that can be used, but is MUCH better than composite video. Using such sources as
Satellite receivers, high-quality VCRs and DVD players (with no component output) will produce a MUCH cleaner and sharper
signal.
• Component Input
Component video is the best type of signal that can be used. The most common sources that use component outputs are DVD
players, and it is highly recommended that component be used when possible. Component video goes one step beyond S-video
in picture quality; chroma (color) information is more resolved and the overall picture appears more well-defined. (be sure to
shut off progressive scan on your DVD player)
• HD1 / HD2
These are High Definition Analog inputs to connect the outputs of high definition sources such as HD tuners and set top boxes,
HD satellite receivers, etc. These inputs will accept signals as RGB, RGBHV or Component Video (YPrPb).
DIGITAL INPUTS:
• DVI 1 / DVI 2
These are High Definition Digital inputs. Runco recommends using these digital inputs whenever possible. Using the DVI 1
and DVI 2 inputs ensures the highest video quality because the signal is carried in the digital domain throughout the entire
signal path, from source component output, through the DHD and finally into the projector. This maintains maximum signal
purity.
Use these inputs to connect Digital High Definition sources that have a DVI output, such as HD tuners and set top boxes,
satellite receivers, DVD players, etc.
ISF Calibration
The VX-2c/DHD system has been designed to incorporate setup and calibration standards established by the Imaging Science
Foundation (ISF). The ISF has developed carefully crafted, industry-recognized standards for optimal video performance and
has implemented a training program for technicians and installers to use these standards to obtain optimal picture quality from
Runco video display devices. Accordingly, Runco recommends that setup and calibration be performed by an ISF certified
installation technician.
All signal types require separate processing. Therefore there is a need to calibrate each and every input separately.
When beginning calibration of the DHD, it is imperative that at least one of the analog SD inputs (Composite, S-Video, RCA
Component) be calibrated first. In doing this, the projector is calibrated to the controller. After one of the SD inputs is calibrated,
calibration of the HD analog or DVI sections can follow.
Once the initial settings have been completed, the “front panel display” (color, tint, sharpness, etc.) can be adjusted for each
aspect ratio. The calibration procedures for these adjustments are outlined in “picture quality adjustments”.
