9
10. Identify the Left Pedal (22), which is marked with an
“L.” Using an adjustable wrench, firmly tighten the
Left Pedal counterclockwise into the Left Crank
Arm (24). Tighten the Right Pedal (not shown) clock-
wise into the Right Crank Arm (not shown). Important:
Tighten both Pedals as firmly as possible. After
using the exercise cycle for one week, retighten
the Pedals.
Adjust the Left Pedal Strap (25) to the desired posi-
tion, and press the end of the Left Pedal Strap onto
the tab on the Left Pedal (22). Adjust the Right
Pedal Strap (not shown) in the same way.
10
11. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
22
25
24
