Ruby Tech GS-2116C User Manual

Page 2

STP/RSTP
---802.1d/1w/1s STP

Network Security

---802.1x access control
---Management Access Policy Control
(L2 ACL)

SNMPv1,v2c Network Management
RFC 1213 MIB (MIB-II)

---Interface MIB
---Address Translation MIB
---IP MIB
---ICMP MIB
---TCP MIB
---UDP MIB
---SNMP MIB

RFC 1757 RMON MIB

---Statistics Group 1
---History Group 2
---Alarm Group 3
---Event Group 9

RFC 1493 Bridge MIB
RFC 1643 Ethernet MIB
Enterprise MIB

Overview

The GS-2116 is an L2 managed Gigabit
switch that supports SNMP, Web UI and
CLI management interface. It is equipped
with 16 Gigabit TP ports and 2 dual media
ports that accommodate optional 10/100/
1000Base-T or SFP modules. In addition,
the switch implements the QoS (Quality of
Service), Mac Filtering Policy, Port Mirror,
VLAN and full L2 protocol. It is suitable for
workgroups or WAN edge application.

G
i

w
i

Gigabit Switch

L2 Managed Switch

RUB

TECH

Networking & Communications

Technical Specifications

LED Description:

Diagnostic LEDs:

Network Interface:

Cable and

Maximum

Length:

Hardware Specifications:

Packing Information

Ordering Information

Optional SFP Module

Note: We recommend the SFP transceiver from the following vendors:
1. Ruby Tech Corporation
2. Agilient Technologies
3. AVAGO Technologies
4. Finisar Corporation

LED Color Function
Global POWER Green -Lit when +5V power is coming up
Global CPU Green -Blinks when CPU is active
Port LINK/ACT Green -Lit when connection with remote device
1-16 is good
-Blinks when any traffic is present
Port 10/100/ Green -Lit Green when TP link on 1000Mbps
1-16 1000Mbps /Amber speed
-Lit Amber when TP link on 100Mbps
speed
-Off when 10Mbps or no link occurs
Port SFP Green - Lit when SFP connection with remote
15,16 device is good
-Blinks when any traffic is present

Weight 2.86kg

Feature Detailed Description

Voltage 100~240 VAC
Frequency 50~60 Hz
Consumption 30W
Ambient Temperature 0 to 40 C
Humidity 5% to 90%
Dimensions 44(H) x 442(W) x 209(D) mm

Safety UL
Complies with FCC Part 15 Class A & CE
Mark

System LED Power
10/100/1000M TP Port Per Port LED Link/Act, 10/100/1000Mbps
Gigabit SFP Module LED SFP

Configuration Connector Port
10/100/1000Mbps TP Jack (RJ-45) TP(RJ-45) 1 to 16
1000Mbps SFP Fiber Module SFP 15, 16

Feature Detailed Description
TP Cat. 5 UTP cable, up to 100m
1000Base-SX SC M-M Up to 220/275/500/550m, which
depends on Multi-Mode Fiber type
1000Base-LX SC S-M Single-Mode Fiber, up to10/30/50Km
1000Base-LX WDM SC S-M Single-Mode Single Fiber, Bidi 20Km

Carton Dimensions (mm) pcs/Carton N.W (KG) G.W (KG)

530x512x345 5 19 20

Ruby Tech Corp.
3F, No.1, Lane 50, Nan Kang Road, Sec.3, Taipei, Taiwan http://www.rubytech.com.tw
TEL:886-2-2785-3961 FAX:886-2-2786-3012 E-mail [email protected]

2008-07.25 Version A

Technical information listed is subject to change without prior notice. All brand names and trademarks are property of their respective owners.

GS-2116C 16-Port GbE L2 Managed Switch with 2 SFP Dual Media

SFP.LC 1000Base-SX GE SFP Fiber Module,
LC Multi-Mode 850nm
SFP.LC.M2 1000Base-SX GE SFP Fiber Module,
LC Multi-Mode 1310nm 2km
