Ruby Tech GS-2216L - Manual

GS-2216L
G
i
g
a
b
i
t
S
w
i
t
c
h
Gigabit Switch
RUB
TECH
Networking & Communications
R
L2 Plus Managed Switch
Technical Specifications Technical Specifications
Standard compliance
---IEEE 802.3x Flow Control capability
---IEEE 802.1q VLAN
---IEEE 802.1p
RoHS Compliance
Performance
Switching capacity:
---16 Gigabit Ethernet ports with non-blocking wise speed performance.
---8 K MAC addresses
---Supports Jumbo frame support, up to 9K
---Unknown Unicast/Broadcast/Multicast Storm Suppression
---Port Mirroring
VLAN
---Port-base VLAN
---IEEE802.1q tag-base VLAN, up to 4k active VLANs
---Q-in-Q is an efficient method for enabling Subscriber Aggregation.
GS-2216L:
16-Port GbE L2 Plus Managed Switch with 4 SFP Dual Media
Key Features Key Features
4 Dual Media for Flexible Fiber
Connection
9KB Jumbo Frame Support
Port Mirroring Helps Supervisor
Monitoring Network
Q-in-Q VLAN for performance &
security and 4094 Vlan entries
(prevision, upgrade via FW)
802.1x Access Control Improve
Network Security
802.1D Compatible, 802.1w Rapid
Spanning Tree and 802.1s Multiple
Spanning Tree
Unknown Unicast/Broadcast/Multicast
Storm Control
Multicast Vlan Management for IPTV
IP-Mac-Port binding for LAN security
Based on Application traffic for QoS and
rate limitation management
DHCP relay agent
Overview
GS-2216L, a 16-port Gigabit L2 Managed
Switch, is a standard switch that meets all
IEEE 802.3/u/x/z Gigabit, Fast Ethernet
specifications. The switch includes 16-Port
10/100/1000Mbps TP and 4-Port Gigabit
TP/SFP Fiber management Ethernet
switch. The switch can be managed
through RS-232 serial port, or through
Ethernet port using CLI or Web-based
management unit, associated with SNMP
agent. With the SNMP agent, the network
administrator can logon the switch to
monitor, configure and control each
port's activity in a friendly way. The
overall network management is
enhanced and the network efficiency is
also improved to accommodate high
bandwidth applications. In addition, the
switch features comprehensive and
useful functions such as QoS (Quality
of Service), Spanning Tree, VLAN, Port
Trunking, Bandwidth Control, Port
Security, SNMP/RMON, IGMP Snooping
capability via the intelligent software. It
is suitable for both metro-LAN and office
applications.
(Prevision, upgrade via FW)
---Multicast Vlan management
QoS
---Supports Layer 4 TCP/UDP Port and ToS Classification
---Supports 802.1p QoS with two level priority queue
---Supports priority in a Q-in-Q tag
Bandwidth Control
---Supports bandwidth rating per port ingress and egress rate limit
1000Mbps with 1Mbps
Protocol
LACP
---Port trunking with 8 trunking group
---up to 16 ports for each group.
GVRP/GARP
---802.1q with GVRP/ GARP
Multicasting
---Supports IGMP snooping including active and passive mode
STP/RSTP/MSTP
---802.1d/1w/1s
Network Security
---802.1x access control for port based and mac based authentication
---Management Access Policy Control
---Access control List
---IP-mac-port binding
---DHCP relay agent
