GS-5105M:
5-Port Gigabit Ethernet Mini Switch
Key Features
Conforms to IEEE 802.3 10BASE-T,
IEEE802.3u 100BASE-TX, IEEE
802.3ab 1000BASE-T and IEEE 802.3x
flow control standards
Supports 10/100Mbps auto-detect half/
full duplex and 1000Mbps at full duplex
Supports TP interface auto MDI/MDI-X
function for auto TX/RX swap
Supports 802.3x flow control pause
packet for full duplex
LEDs to indicate: 10/100/1000Mbps,
Link/Act. and Power Status
Overview
GS-5105 meets the demand for bandwidth
as 5 port Desktop Gigabit switch. This
desktop switch seamlessly integrates with
the rest of the network through its auto-
negotiating, non-blocking design. To break
through the bottlenecks at the core of
network, GS-5105 provides up to 10Gbps
aggregate bandwidth and seamless
migration and the most cost effect method
for bringing high speed networking to the
desktop
Easy Installation and Configuration
GS-5105M conforms to plug and play for
easy installation and use. With diagnostic
LEDs, network and port status can be easily
monitoring and trouble-shooting. GS-5105M
also build in wiring crossover on all ports
allows connection to server or PC without
worrying about cabling.
GS-5105M
Technical Specifications
Standard compliance :
---IEEE 802.3 10Base-T Ethernet(twisted-pair copper)
---IEEE 802.3u 100Base-TX Ethernet(twisted-pair copper)
---IEEE 802.3ab 1000Base-T Ethernet(twisted-pair copper)
---ANSI/IEEE 802.3 Auto-negotiation
MAC Address : 8K
Network Interface : 5 10/100/1000Mbps RJ-45 ports
Flow control :
---IEEE802.3x compliant for full-duplex
---Back pressure flow control for half-duplex
Media :
---10BASE-T: UTP Cat. 3, 4, 5 or up
100BASE-TX: UTP Cat. 5 or up ---
1000BASE-T: UTP Cat. 5 or up ---
Transmission Mode: 10/100Mbps, full/half-duplex (Auto-sensing)
Transfer Rate:
10Mbps: 14880pps (64 Bytes Package) ---
100Mbps: 148800pps (64 Bytes Package) ---
1000Mbps: 1488000pps (64 Bytes Package) ---
Buffer Memory: 112KB per unit
Switching Method : Store & forward
Power Supply: External Switching
Power(DC 5V/2A)
Operation Temperature: 0 to 50 C
Operation Humidity: 0% to 90%
Dimensions: 27(H) x 159(W) x 102(D) mm
Complies with FCC Class A, CE Mark Approval
Ordering Information
GS-5105M: 5 Port 10/100/1000M Gigabit Ethernet Mini Switch
