Ruby Tech GS-1148L - Manual

GS-1148L
G
i
g
a
b
i
t
S
w
i
t
c
h
Gigabit Switch
Web Smart Switch
GS-1148L: 48-Port GbE Web Smart Switch with 4 SFP Dual Media
Key Features Key Features
Standard compliance
---IEEE 802.3 10Base-T Ethernet
(twisted-pair copper)
---IEEE 802.3u 100Base-T Ethernet
(twisted-pair copper)
---IEEE 802.3ab 1000Base-T Ethernet
(twisted-pair copper)
---IEEE 802.3z 1000Base-X Ethernet
---IEEE 802.3x flow control capability
---ANSI/IEEE 802.3 auto-negotiation
---IEEE 802.1q VLAN
RoHS Compliance
Subscriber Interface
---48 Gigabit Ethernet ports
---Auto-negotiation
---Auto-MDIX
---Backpressure flow control for half
duplex.
---802.3x flow control for full duplex.
---Port 45 to 48 are TP/SFP Fiber auto
sense
---Connector: 44 RJ-45 plus 4 TP/SFP
module
Performance
Switching capacity:
---48Gbps forwarding bandwidth for
switch, non-blocking switch fabric and
wire speed performance
---8 K MAC addresses
---768 KB on-chip frame buffer
---Jumbo frame support up to 16K
VLAN
---Port-base VLAN
---IEEE802.1q tag-base VLAN, 4094
max
QoS
---Supports packet classification by each
port or vlan ACL rule
---Supports four level priority queues
and prioritized by Ethernet type, vlan
tag, IP, UDP, TCP and flow.
Bandwidth Control
---Supports bandwidth rating that
includes per port ingress and egress
rate and the rate is 1% of the port
speed.
Port Trunk
---Port trunking with 8 trunking groups
---Up to 12 ports for each group
Broadcast Storm
---Broadcast Storm suppression
Port Mirroring
---All port support port mirroring
Benefits Benefits
QoS with Four Priority Queues
Extensive QoS features make the solution ideal for real-time
applications like VoIP and IPTV. The 4 priority queues together with the
Weighted Round Robin and Strict Priority scheduling techniques
facilitate efficient co-existence of real-time traffic with data traffic
allowing them each to meet their QoS needs. Individual users or
applications can be prioritized above others using various Class of
Service options by port, layer 2 priority (802.1p), Layer 3 priority (TOS
or DSCP), IPv6 Traffic Class or TCP/UDP service number.
Enhancing Security, Traffic Flow Classification and Prioritize by
Powerful ACL rule
Access control lists (ACLs) provide an effective means for limiting the
types of traffic permitted on a network; thus enhancing security by
preventing unauthorized activity. ACLs are, as the name implies, a
series of lists that are processed for every frame received by the switch.
Each list consists of a set of rules. Each rule is defined by a set of
criteria. It is the flexibility that the switch allows in configuring these
lists, rules and criteria that gives the ACLs their power.
Port Mirroring
Port mirroring copies traffic from a specific port to a target port. This
mechanism helps track network errors or abnormal packet transmission
without interrupting the flow of data.
VLAN for Performance & Security
The VLAN feature in the switch offers the benefits of both security and
performance. VLAN is used to isolate traffic between different users and
thus provides better security. Limiting the broadcast traffic to within the
same VLAN broadcast domain also enhances performance.
Port Trunk for Bandwidth Aggregation
The Gigabit ports can be combined together to create a multi-link load-
sharing trunk. Up to 12 Gigabit ports can be set up per trunk. The switch
supports up to 8 trunking groups. Port trunks are useful for switch-to-
switch cascading, providing very high full-duplex speeds.
Trap Event for Exception Management
We use SNMP Trap mechanism to inform supervisor to know the instant
abnormal status of the switch.
4 Dual Media Ports for Flexible Fiber Connection
The dual media ports are provided for flexible fiber connection. You can
select to install optional transceiver modules in these slots for short,
medium or long distance fiber backbone attachment. Use of the SFP will
disable their corresponding built-in 10/100/1000Base-T connections.
Build-in Web-base Management
Instead of using CLI interface, we provide a more convenient GUI for
user. We just need to configure switch via Web Browser. It is more
quickly for user to familiar the method to control switch on the basis of
this design.
