2. Introduction
This product is a PROM programming adapter for the Renesas M16C/60 Series of 16-bit MCUs. The
adapter is a tool that can be used to write programs into internal PROM of an MCU using a PROM
programmer commercially available. This user's manual describes specifications of the PCA7412F-
100, PCA7412L-100, PCA7412G-100 and PCA7413F-80 and how to use them.
Figure 2.1 shows the external view of the PROM programming adapter and its constituent parts.
Figure 2.1 External view of the programming adapter and its constituent parts
2.1 Things to Check When Unpacking
This product package consists of the following parts. Check to see that it contains all the parts shown
in Table 2.1 below.
Table 2.1 Contents
If any part is missing or there is any doubt about your product package, contact your local distributor.
PCA7412F-100
package
PCA7412F-100
PCA7412L-100
package
PCA7412L-100
PCA7412G-100
package
PCA7412G-100
PCA7413F-80
package
PCA7413F-80 Main unit
Interface unit
Connector
User's
Manual
PCA7412B
PCA7476E (32-pin)
PROM Programming Adapters for M16C/60 Series User's Manual
(This manual)
PCA7412C
PCA7402E (32-pin)
PCA7412B
PCA7476E (32-pin)
