3.5 Setting Programming Area
To write programs into the MCU, be sure to set the programming area. And also, specify a device by
the PROM programmer. For programming areas and devices, see Tables 3.2 and 3.3.
Table 3.2 List of programming areas (other than M16C/6V)
CAUTION
When Setting a Programming Area:
• Specify a proper programming mode, because an incorrect setting can cause fatal
damage to the MCU.
• The programming method for M5M27C101, M5M27C201 or M5M27C401 mode
is the byte-programming method.
• The MCUs listed above are shown as examples. Therefore, some MCUs may not be
available in the future.
Table 3.3 List of programming areas (M16C/6V)
Type name
ROM area
of MCU Programming
area
Example
90000h--AFFFFh
D0000h--FFFFFh
M5M27C401
MCU PROM programmer
Device
ROM size
10000h--2FFFFh
50000h--7FFFFh
OSD ROM
(128 KB)
Internal ROM
(192 KB)
M306V2EEFS M306VXEE
Type name
ROM area
of MCU Programming
area
Example
F8000h--FFFFFh
F0000h--FFFFFh
M5M27C101
MCU PROM programmer
Device
ROM size
18000h--1FFFFh
10000h--1FFFFh
32 KB
64 KB
M30612E4FP
M30613E4TGP
M30600E8FP
M306XXE4
M306XXE8
M306XXEC
96 KB
128 KB
M306XXEA 08000h--1FFFFh
20000h--3FFFFh
E8000h--FFFFFh
E0000h--FFFFFh M30610ECFP
N/A
M5M27C201
