3.4 Inserting an MCU into the Adapter
As shown in Figure 3.3, insert the MCU into the IC socket aligning the No. 1 pin. This also applies
to the PCA7412L-100, PCA7412G-100, and PCA7413F-80.
Be careful when inserting the MCU because an incorrect insertion can cause fatal
damage to the MCU.
Figure 3.3 Inserting an MCU
Top view
