4. Specifications
4.1 Specifications
Tables 4.1 lists common specifications of the programming adapters, and Table 4.2 individual
specifications.
Table 4.1 Common specifications
Table 4.2 Individual specifications
Note: As this product is designed to support the same packages of the M16C/60 Series, it is ready
for most of the products which will be introduced in the future.
Product name
PCA7412F-100
PCA7412L-100
PCA7412G-100
PCA7413F-80
Item
MCU
IC socket
Internal ROM type
Description
M16C/60 Series 100-pin QFP (100P6S-A)
e.g. M30600E8FP
IC51-1004-814-6 (made by Yamaichi Electronics Co. Ltd.)
EPROM
M16C/60 Series 100-pin LCC (100D0)
e.g. M30600E8FS
IC51-1004-804 (made by Yamaichi Electronics Co. Ltd.)
EPROM
M16C/60 Series 100-pin QFP (100P6Q-A)
e.g. M30600E8GP
IC51-1004-809 (made by Yamaichi Electronics Co. Ltd.)
EPROM
M16C/60 Series 80-pin QFP (80P6S-A)
e.g. M30601E8GP
IC51-804-711 (made by Yamaichi Electronics Co. Ltd.)
EPROM
IC socket
Internal ROM type
IC socket
Internal ROM type
IC socket
Internal ROM type
MCU
MCU
MCU
Operating clock frequency
8 MHz
(Supplied by the ceramic oscillator mounted on the adapter)
Supplied from Vcc of the PROM programmer
Board to insert a programmable MCU
(IC socket for MCU mounted on it)
Interface board
(Connected by two rows of standard-pitch 18-pin connectors
and two rows of standard-pitch 16-pin connectors to the
upper and lower boards)
Board to connect to the PROM programmer
(Standard-pitch 32-pin pin-header mounted)
Board
configuration
Power supply
Connector
(PCA7402E or
PCA7476E)
Main unit
Interface unit
(PCA7412B or
PCA7412C)
