Section 3 Connection Procedures
Rev. 1.00 Nov. 18, 2008 Page 13 of 18
REJ10J1937-0100
3.2.2 External Dimensions
The external dimensions of the expansion AUD trace unit, emulation memory unit, EV-chip unit,
common user-system interface adaptor cable (board unit), common user-system interface adaptor
cable (cable unit), and user-system interface converter board are shown in figure 7.
125.0
90.0
Expansion AUD trace unit
125.0
90.0
110.0
20.0
Unit: mm
±0.05
±0.10
±0.15
±0.20
±0.30 to 1.2
1.3 to 2.0
2.1 to 5.0
5.1 to 10.0
10.1 to
35.0
43.5
267.0
241.0
35.0
125.0
90.0
Emulation memory unit
Ev-chip unit
Common user-system interface adaptor cable (cable unit)
User-system interface converter board
Dimensions and tolerance
Dimensions Tolerance
Common user-system interface adaptor cable (board unit)
90.0
5.81 49.0
60.0
Figure 7 External Dimensions of the Expansion AUD Trace Unit, Emulation Memory Unit,
EV-Chip Unit, Common User-System Interface Adaptor Cable (Board Unit), Common
User-System Interface Adaptor Cable (Cable Unit), and User-System Interface Converter
Board
