Section 1 Configuration
Rev. 1.00 Nov. 18, 2008 Page 2 of 18
REJ10J1937-0100
CAUTION
1. Use a BSSOCKET272Z2021RE21N socket (manufactured
by Tokyo Eletech Corporation), and a
CSPLUG/W272Z2021RE01 (manufactured by Tokyo
Eletech Corporation) for the PRBG0272FA-A package IC
socket, and IC socket plug, respectively, on the user
system.
2. To connect the emulator with user-system interface
converter board, the common user-system interface
adaptor cable (R0E200F1CKL00) must be obtained
separately.
3. To mount the MCU directly on the user system, use a
LSPACK272Z20221RE02 top cover (manufactured by
Tokyo Eletech Corporation) for the IC socket.
Table 1 R0E572546CBF10 Components
No. Component Quantity Remarks
1 User-system interface
converter board
1 R0E572546CBF10
2 IC socket 1 BSSOCKET272Z2021RE21N
PRBG0272FA-A package (mounted on the user
system)
3 IC socket plug 1 CSPLUG/W272Z2021RE01
For the PRBG0272FA-A package (for the connection
with the user system)
4 User’s manual 1 User’s manual for R0E572546CBF10 (this manual)
