Section 3 Connection Procedures
Rev. 1.00 Nov. 18, 2008 Page 5 of 18
REJ10J1937-0100
Section 3 Connection Procedures
3.1 Connecting User System Interface Cable to User System
WARNING
Always switch OFF the user system and the emulator
product before the USER SYSTEM INTERFACE CABLE is
connected to or removed from any part. Before connecting,
make sure that pin 1 on both sides are correctly aligned.
Failure to do so will result in a FIRE HAZARD and will
damage the user system and the emulator product or will
result in PERSONAL INJURY. The USER PROGRAM will be
LOST.
