Installation Verification
Procedure
Register
❏
Before proceeding any further, please verify that
the user registration form has been completed and
mailed.
Mechanical Installation
❏ Verify that the mechanical installation has been
completed in accordance with the instructions.
Outdoor Air Temperature Sensor
❏ Verify that all Outdoor Air Temperature Sensor
installation parameters have been met.
Water Temperature Sensor
❏ Verify that the Water Temperature Sensor installa-
tion parameters have been met.
Optional Equipment
❏ Verify that optionally ordered equipment installa-
tion parameters have been met.
System Module Installation
❏ Verify electrical power wiring connections.
❏
Verify electrical connection torque requirements.
❏
Verify Outdoor Air Temperature Sensor wiring.
❏ Verify Water Temperature Sensor wiring.
❏ Verify Power Test has been completed successful-
ly.
CONTROLLER
FAMILIARIZATION
This system is configured utilizing a LCD display (2
lines, 20 characters each) with keypad for data entry.
Open the front cover of the Control Box for access to
the LCD display and keypad. Open the control panel to
gain access to the interface connections.
REFER TO THE TABLES ON THE FOLLOWING
PAGES AND THE DISPLAY SCREENS FOR
DETAILED CONFIGURATION INSTRUCTIONS.
NOTE: Controller is shipped with factory defaults.
your system may require different program settings.
