12
MT-90U Basic Operation
1.
Connect the supplied AC adaptor and power cord.
2.
Connect the AC adaptor to the DC In jack on the MT-90U’s rear panel.
Place the AC adaptor so the side with the indicator (see illustration) faces upwards and the side with textual
information faces downwards.
* The indicator will light up when you plug the AC adaptor into an AC outlet.
3.
Secure the power cord with the cord hook as shown below.
.
To prevent the inadvertent disruption of power to your unit (should the plug be pulled
out accidentally), and to avoid applying undue stress to the AC adaptor jack, anchor
the power cord using the cord hook, as shown in the illustration.
4.
Plug the power cord into a power outlet.
Be sure to use the AC adaptor and power cord supplied with the MT-90U.
Setting Up
Connecting the AC Adaptor
Power
Indicator
To Power Outlet
AC Adaptor
Power Cord
