ASSEMBLY
1625 01/11
Assembly Section 3-11
© 2011 Alamo Group Inc.
ASSEMBL
Y
PARTS LIST - LOADER AND BOOM
ITEM
PART NO.
DESCRIPTION
QTY
1.
55030
BOOM
1
2.
55271
COLUMN-RH
1
3.
55032
COLUMN-LH
1
4.
55033
SPACER
4
5.
55034
ROD BUCKET
2
6.
55035
LINK BUCKET-RH
1
7.
55036
LINK BUCKET-LH
1
8.
54076
COVER
2
9.
54207
INDICATOR
1
10.
54219
COVER
1
11.
54208
STAND
2
12.
54209
LINK-STAND
2
13.
54210
SUPPORTER
2
14.
54211
PIN
2
15.
54212
PIN
2
16.
55037
CYLINDER-BOOM
2
17.
55038
CYLINDER-BUCKET
2
18.
54215
PIN
4
19.
54217
PIN
8
20.
55039
PIN
4
21.
55040
PIN-LEVER
2
22.
54123
PIN-LINK
2
23.
54122
SNAP RING
4
24.
54217
PIN-COTTER
2
25.
54128
PIN-SPLIT
1
26.
49040-34
BOLT
8
27.
701511C
M8 PLAIN WASHER
4
28.
701611C
M8 SPRING WASHER
8
29.
49040-25
HEXB METRIC 12 - 1.5P - 20MM
16
30.
701512C
M16 PLAIN WASHER
16
31.
00755954
M10 SPRING WASHER
16
32.
49040-38
HEXB METRIC 20 - 2.5P - 100MM
2
33.
54134-1
M12 LOCKNUT
2
34.
49040-39
HEXB METRIC 20 - 2.5P - 100MM
2
35.
54134-3
M20 LOCKNUT
2
