Renesas H8SX/1582 User Manual
Page 26
Section 2 Connection Procedures
Rev. 3.00 Sep. 08, 2008 Page 12 of 18
REJ10J1396-0300
2.5
Resulting Dimensions after Connecting User System Interface Cable
The resulting dimensions, after connecting the user system interface cable head to the user system,
are shown in figure 8.
13.3
21.5
Cable head
User system
Unit: mm
Tolerance: ±0.5 mm
IC socket
(NQPACK120SE-ND
manufactured by
Tokyo Eletech Corporation)
Figure 8 Resulting Dimensions after Connecting User System Interface Cable
