Section 1 Configuration
Rev. 3.00 Sep. 08, 2008 Page 2 of 18
REJ10J1396-0300
Table 1 lists the HS1582ECH61H components. Please make sure you have all of these
components when unpacking.
Table 1 HS1582ECH61H Components
No. Component Quantity Remarks
1 Cable body 1 Cable
2 Cable head 1
3 IC socket 1 For the PLQP0120LA-A package
4 Socket cover 1 For installing an PLQP0120LA-A packaged MCU
5 Screws (M2.0 x 10 mm) 4 For fastening cable head
6 Screws (M2.0 x 6 mm) 4 For installing an PLQP0120LA-A packaged MCU
7 Guide pins (
φ1 mm)
3 For determining the IC socket location
8 Screwdriver 1 For tightening screws
9 Documentation 1 User’s manual for HS1582ECH61H (this manual)
