Page 25
Section 2 Connection Procedures
Rev. 3.00 Sep. 08, 2008 Page 11 of 18
REJ10J1396-0300
2.4
Dimensions for User System Interface Cable Head
The dimensions for the user system interface cable head are shown in figure 7.
Unit: mm
Tolerance: ±0.5
mm
63.5
66.04
20.25
23.0
20.25
23.0
Figure 7 Dimensions for User System Interface Cable Head
