Section 2 Connection Procedures
Rev. 3.00 Sep. 08, 2008 Page 4 of 18
REJ10J1396-0300
2. After making sure the direction of the cable body connector is correct, firmly insert the cable
body connector into the emulator station socket (figure 2).
E6000H
HS1527KEPH60H
emulator station
RENESAS
Cable body connector
User system interface cable
Figure 2 Example of the HS1527KEPH60H Emulator Station
