Mounting on the Hi-Hat Stand
1. Adjust the gap between the top hi-hat and
bottom hi-hat to a clearance of approximately
10 mm, then tighten the clutch screw.
fig.Gap.e
* Although the gap can be adjusted to a clearance that makes
playing the hi-hat easier, setting too narrow or wide a gap can
cause improper function of the unit and prevent the hi-hat from
sounding as you intend. Setting the gap to
10 mm provides
the most natural feel when playing the VH-12.
2. Change the spring tension by adjusting the hi-
hat stand.
For instructions on adjusting the tension, refer to the
owner’s manual for your hi-hat stand.
* The tension may not be adjustable on some stands.
While playing, always align the marks on the top hi-hat
and bottom hi-hat (
▼ and ▲ ) to prevent malfunction.
fig.Mark
(6) Adjusting the Hi-Hat
10 mm
(3/8")
Clutch
Screw
