6
MIDI Implementation
2. Data Transmission
n Channel Voice Messages
l
Note off
Status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note off velocity: 00H - 7FH (0 - 127)
l
Note on
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
l
Control Change
Status 2nd byte 3rd byte
BnH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = Controller number: 00H - 77H (0 - 119)
vv = Control value: 00H - 7FH (0 - 127)
m Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 87 00H - 87 20H (bank.17281, bank.17313)
* These messages are transmitted when Patch is selected. But not transmitted when
TX PROGRAM CHANGE or TX BANK SELECT parameter (SYSTEM COMMON MIDI) is
OFF.
* The Patches corresponding to each Bank Select are as follows.
BANK SELECT | PROGRAM | GROUP | NUMBER
MSB | LSB | NUMBER | |
-----+-----------+-----------+----------------------+-----------
087 | 000 | 001 - 128 | User Patch | A-1 - H-8
| 064 | 001 - 128 | Preset Patch | A-1 - H-8
088 | 064 | 001 - 008 | Preset PCM Patch | 1 - 8
m Modulation (Controller number 1)
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
m Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Volume: 00H - 7FH (0 - 127)
m Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
m Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
l
Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H - FH (ch.1 - 16)
pp = Program number: 00H - 7FH (prog.1 - prog.128)
l
Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
n
System Realtime Messages
l
Active Sensing
Status
FEH
* This message is transmitted at intervals of approximately 250 msec.
