21
MIDI Implementation
As the data size of Patch Arpeggio Pattern is 00 00 00 42H, summation of the size and
the start address of Temporary Patch Arpeggio Pattern (Note 16) will be;
10 00 00 00H
00 00 1C 00H
+) 00 00 00 42H
10 00 1C 42H
And the size that have to be got should be;
10 00 1C 42H
-) 10 00 00 00H
00 00 1C 42H
Therefore the system exclusive message should be sent is;
F0 41 10 00 00 41 11 10 00 00 00 00 00 1C 42 ?? F7
(1) (2) (3) (4) (5) address data checksum (6)
(1) Exclusive Status, (2) ID (Roland), (3) Device ID (17),
(4) Model ID (SH-01), (5) Command ID (RQ1), (6) End of Exclusive
Calculating the checksum as shown in , we get a message of F0 41 10 00
00 41 11 10 00 00 00 00 00 1C 42 12 F7 to be transmitted.
n
ASCII Code Table
Patch Name, etc., of MIDI data are described the ASCII code in the table below.
+------+------+------++------+------+------++------+------+------+
| D | H | Char || D | H | Char || D | H | Char |
+------+------+------++------+------+------++------+------+------+
| 32 | 20H | SP || 64 | 40H | @ || 96 | 60H | ` |
| 33 | 21H | ! || 65 | 41H | A || 97 | 61H | a |
| 34 | 22H | " || 66 | 42H | B || 98 | 62H | b |
| 35 | 23H | # || 67 | 43H | C || 99 | 63H | c |
| 36 | 24H | $ || 68 | 44H | D || 100 | 64H | d |
| 37 | 25H | % || 69 | 45H | E || 101 | 65H | e |
| 38 | 26H | & || 70 | 46H | F || 102 | 66H | f |
| 39 | 27H | ` || 71 | 47H | G || 103 | 67H | g |
| 40 | 28H | ( || 72 | 48H | H || 104 | 68H | h |
| 41 | 29H | ) || 73 | 49H | I || 105 | 69H | i |
| 42 | 2AH | * || 74 | 4AH | J || 106 | 6AH | j |
| 43 | 2BH | + || 75 | 4BH | K || 107 | 6BH | k |
| 44 | 2CH | , || 76 | 4CH | L || 108 | 6CH | l |
| 45 | 2DH | - || 77 | 4DH | M || 109 | 6DH | m |
| 46 | 2EH | . || 78 | 4EH | N || 110 | 6EH | n |
| 47 | 2FH | / || 79 | 4FH | O || 111 | 6FH | o |
| 48 | 30H | 0 || 80 | 50H | P || 112 | 70H | p |
| 49 | 31H | 1 || 81 | 51H | Q || 113 | 71H | q |
| 50 | 32H | 2 || 82 | 52H | R || 114 | 72H | r |
| 51 | 33H | 3 || 83 | 53H | S || 115 | 73H | s |
| 52 | 34H | 4 || 84 | 54H | T || 116 | 74H | t |
| 53 | 35H | 5 || 85 | 55H | U || 117 | 75H | u |
| 54 | 36H | 6 || 86 | 56H | V || 118 | 76H | v |
| 55 | 37H | 7 || 87 | 57H | W || 119 | 77H | w |
| 56 | 38H | 8 || 88 | 58H | X || 120 | 78H | x |
| 57 | 39H | 9 || 89 | 59H | Y || 121 | 79H | y |
| 58 | 3AH | : || 90 | 5AH | Z || 122 | 7AH | z |
| 59 | 3BH | ; || 91 | 5BH | [ || 123 | 7BH | { |
| 60 | 3CH | < || 92 | 5CH | ¥ || 124 | 7CH | | |
| 61 | 3DH | = || 93 | 5DH | ] || 125 | 7DH | } |
| 62 | 3EH | > || 94 | 5EH | ^ ||------+------+------+
| 63 | 3FH | ? || 95 | 5FH | _ |
+------+------+------++------+------+------+
D: decimal
H: hexadecimal
* “SP” is space.
