Understanding the component location, Front view, Rear view – Ricoh Fax 2210L User Manual
Page 20: Front view rear view
G
ETTING
S
TARTED
1.6
Understanding the Component
Location
These are the main components of your machine:
Front View
Rear View
Control Panel (See page 1.7)
Handset
(for America only)
Front Cover
Paper Tray
Front Output Tray (Face down)
Document Input
Support
Automatic Document
Feeder
Toner Cartridge
Paper Output
Extension
Manual Feeder
Manual Feeder
Guides
Paper Level
Indicator
Document
Guides
Document Output
Tray
Parallel Connector
(for MFP model only)
Power Switch
USB Connector
(for MFP model only)
Rear Cover
Rear Output
Slot (Face up)
AC Power Cord
Connector
EXT Jack
*
Line Jack
*
If your country has a different
telephone connection system,
this socket may be blocked.
