J3
Pin Circuit Net Name Device
Pin
Pin Circuit Net Name Device
Pin
1 TMR1 33 2 Up 34
3 NMIn 35 4 UD 36
5 Vp 37 6 Wp 38
7 Vn 39 8 Wn 40
9 PTRX 41 10 PTTX 42
11 PTCK 43 12 SCK3 44
13 RXD 45 14 TXD 46
15 LED2 47 16 SCK3_2 48
Table 9-3: J3
J4
Pin Circuit Net Name Device
Pin
Pin Circuit Net Name Device
Pin
1 RXD_2 49 2 TXD_2 50
3 IRQ0n 51 4 IRQ1n 52
5 IRQ2n 53 6 LED3 54
7 IO_3 55 8 IO_2 56
9 IO_1 57 10 IO_0 58
11 AN3 59 12 AN2 60
13 AN1 61 14 AN0 62
15 AD_POT 63 16 PIN64 64
Table 9-4: J4
17
